Recommended Lubricants and Capacities
To help achieve proper engine and powertrain performance and durability, use only lubricants of the proper quality. The correct lubricants also help promote engine efficiency that results in improved fuel economy.
These lubricants and fluids are recommended for use in your vehicle.
|
Lubricant |
Volume |
Classification |
|
|
Engine oil *1*2 Recommends
|
2.5 T-GDI |
6.5 US qt. (6.2 ℓ) |
API SN PLUS /SP or ILSAC GF-6 *3 SAE: 0W-30 |
|
3.5 T-GDI |
7.4 US qt. (7.0 ℓ) |
API SN PLUS/SP or ILSAC GF-6 *3 SAE: 0W-30 |
|
|
Automatic transmission fluid |
9.7 US qt. (9.2 ℓ) |
GS ATF SP-IV-RR, Genesis/HYUNDAI genuine ATF SP-IV-RR or other brands meeting the above specification approved by Genesis Customer Care |
|
|
Engine coolant |
2.5 T-GDI |
9.1 US qt. (8.6 ℓ) |
Mixture of antifreeze and water (Phosphate-based Ethylene glycol coolant for aluminum radiator) |
|
3.5 T-GDI |
10.2 US qt. (9.7 ℓ) |
||
|
Liquid-cooled intercooler coolant |
2.5 T-GDI |
1.56 US qt. (1.48 ℓ) |
|
|
3.5 T-GDI |
1.56 US qt. (1.48 ℓ) |
||
|
Brake fluid *4 |
As required |
SAE J1704 DOT-4LV, FMVSS116 DOT-4, ISO4925 CLASS-6 |
|
|
Front differential oil (AWD) *5 |
0.71±0.026 US qt. (0.67±0.025 ℓ) |
HYPOID GEAR OIL API GL-5 SAE 75W/85 (SK HK SYN GEAR OIL 75W85 FM PLUS OR EQUIVALENT) |
|
|
Rear differential oil *5 |
1.27±0.05 US qt. (1.2±0.05 ℓ) |
HYPOID GEAR OIL API GL-5 SAE 75W/85 (SK HK SYN GEAR OIL 75W85 FM PLUS OR EQUIVALENT) |
|
|
Transfer case oil (AWD) |
Gear/Clutch : 0.44 ± 0.022 US qt. (0.42 ± 0.021 ℓ) Actuator : 0.28 ± 0.011 US qt. (0.27 ± 0.010 ℓ) |
SHELL TF0870B |
|
|
e-LSD oil |
0.43 ± 0.016 US qt. (0.41 ± 0.015 ℓ) |
SHELL TF0870C |
|
|
Fuel |
17.43 US gal. (66 ℓ) |
Refer to “Fuel Requirements” in chapter 1. |
|
Refer to the recommended SAE viscosity numbers on the next page.
Engine oils labeled Energy Conserving Oil are now available. Along with other additional benefits, they contribute to fuel economy by reducing the amount of fuel necessary to overcome engine friction. Often, these improvements are difficult to measure in everyday driving, but in a year’s time, they can offer significant cost and energy savings.
Requires < API SN PLUS (or above) full synthetic> grade engine oil. If a lower grade engine oil (mineral oil including Semi-synthetic) is used, then the engine oil and engine oil filter must be replaced as indicated for severe maintenance conditions.
To maintain the best braking performance and ABS/ESC performance, we recommend that you use genuine brake fluid that conform to specifications.
If the front/rear differential is submerged, we recommend that you visit an authorized retailer of Genesis Branded products to replace the differential oil.
