Recommended lubricants and capacities
To help achieve proper engine and powertrain performance and durability, use only lubricants of the proper quality. The correct lubricants also help promote engine efficiency that results in improved fuel economy.
These lubricants and fluids are recommended for use in your vehicle.
|
Lubricant |
Volume |
Classification |
||
|
Engine oil*1*2 Recommends
|
2.5 T-GDi |
6.34 US qt. (6.0 ℓ) |
API SN PLUS/SP or ILSAC GF-6*3 SAE: 0W-30 |
|
|
3.3 T-GDi |
7.29 US qt. (6.9 ℓ) |
ACEA A5/B5*4 SAE: 5W-30 |
||
|
Automatic transmission fluid |
9.72 US qt. (9.2 ℓ) |
GS ATF SP-IV-RR Genesis/Hyundai genuine ATF SP-IV-RR or other brands meeting the above specification approved by Genesis Motor America |
||
|
Engine coolant |
2.5 T-GDi |
9.4 US qt. (8.9 ℓ) |
Mixture of antifreeze and water (Phosphate-based Ethylene glycol coolant for aluminum radiator) |
|
|
3.3 T-GDi |
11.1 US qt. (10.5 ℓ) |
|||
|
Liquid-cooled intercooler coolant |
2.5 T-GDi |
2.63 US qt. (2.49 ℓ) |
||
|
Brake fluid*5 |
As required |
FMVSS116 DOT-4 |
||
|
Rear differential oil*6 (without LSD) |
2.5 T-GDi |
1.26 US qt. (1.2 ℓ) |
HYPOID GEAR OIL API GL-5 SAE 75W/85 (SK HK SYN GEAR OIL 75W85 or equivalent) |
|
|
3.3 T-GDi |
1.37 US qt. (1.3ℓ) |
|||
|
Rear differential oil*6*7 (with LSD) |
2.5 T-GDi |
1.37 US qt. (1.3 ℓ) |
HYPOID GEAR OIL API GL-5 SAE 75W85 (SK HK JL SYN LSD GEAR OIL 75W85 PLUS OR SK HK SYN GEAR OIL 75W85 FM PLUS) |
|
|
3.3 T-GDi |
1.47 US qt. (1.4 ℓ) |
|||
|
Front differential oil (AWD)*6 |
0.74 US qt. (0.7ℓ) |
HYPOID GEAR OIL API GL-5 SAE 75W/85 (SK HK SYN GEAR OIL 75W85 or equivalent) |
||
|
Transfer case oil (AWD) |
Gear/Clutch |
0.60 US qt. (0.57 ℓ) |
SHELL TF 0870B |
|
|
Actuator |
0.26 US qt. (0.25 ℓ) |
|||
|
Fuel |
15.8 US gal. (60 ℓ) |
Refer to the "Fuel requirements" section in chapter 1. |
||
Refer to the "Recommended SAE viscosity number" section.
If the above recommended specification oil is not available, SAE 0W-30 grade synthetic oil can be used. If mineral oil or semi-synthetic oil is used, it is a severe maintenance condition in terms of engine oil change.
Requires <API SN PLUS (or above) Full synthetic> grade engine oil. If a lower grade engine oil (mineral oil including Semi-synthetic) is used, then the engine oil and engine oil filter must be replaced as indicated severe maintenance condition.
Requires <API Latest (or ILSAC Latest) or ACEA A5/B5 Full synthetic> grade engine oil. If a lower grade engine oil (mineral oil including Semi-synthetic) is used. Then the engine oil and engine oil filter must be replaced as indicated severe maintenance condition.
To maintain the best braking performance and ABS/ESC performance, use genuine brake fluid that conform to specifications.
If the front/rear differential is submerged, visit an authorized retailer of Genesis Branded products to immediately replace the differential oil.
Be sure to inject oil for exclusive use of LSD when replacing Rear Differential Oil (if equipped with Limited Slip Differential).
